Powder metallurgy materials for household appliances

Many household appliances will now used in powder metallurgy process to make, take the common electric fan, refrigerators, computers, air conditioning, but also with respect to the traditional process, used in powder metallurgy price and cost far below the traditional process, today Xiaobian accompany you to understand household appliances in powder metallurgy materials together!

In the development of household electrical appliances, the early stage of powder metallurgy is mainly made of copper based oil bearing bearing. Difficult parts, such as high precision, complex shape of compressor cylinder cover, cylinder liner, as well as some special performance requirements of the product also gradually developed. Our country just all kinds of compressor of powder metallurgy structural parts demand, such as air conditioners and refrigerators for rotary compressor, the annual output of about 355 million units, and each will need to powder metallurgy structural parts 80-350g.

Connecting rod type compressor for refrigerator and its annual output is about 827 million units, and each requires powder metallurgy structural parts 100g; sliding screw type compressor of air-conditioner and refrigerator, its annual output is about 310 million units, and each is need to powder metallurgy structural parts 30~200g. Household electric appliance is a big market of powder metallurgy structural parts, but these parts are not only complex in shape, but also require high temperature and high pressure. This is also very useful for powder metallurgy factory to further improve the level of technology and equipment and technical design.

In order to reduce the noise, has entered the household washing machine and an electric fan motor is used in powder metallurgy bearing, especially low noise, can substitute for copper in iron base oil bearing, the noise of the whole machine for ~ 40dB powder metallurgy oil bearing. Because of its self lubrication, low noise, cheap price, suitable for mass production, so it is widely used in the powder metallurgy oil bearings, such as cameras, tape recorders, etc..

Development trend of powder metallurgy technology

The development trend of powder metallurgy technology in the future, there are 5 major points, Shenzhen powder metallurgyfactory ZCMIM with you to understand:

1, the vast majority of refractory metals and compounds, pseudo alloys, porous materials can only be manufactured by powder metallurgy method.

2, due to the powder metallurgical method can be pressed into the final size of the compact, and do not need or need little subsequent mechanical processing, it can greatly save metal, reduce the cost of products.

3, due to the technology of powder metallurgy in the production process of the material does not melt materials, not mixed with impurities caused by crucible and deoxidizing agent and sintering general in vacuum and in a reducing atmosphere, not afraid of oxidation nor to any material pollution.

4, powder metallurgy method can guarantee the accuracy and uniformity of the composition ratio of the material.

5, powder metallurgy is suitable for the production of the same shape and the number of products, especially gear and other high processing costs of products, powder metallurgy process can greatly reduce production costs.

Apple watch adapter, metal injection molding process

Metal powderinjection molding technology has obvious advantages compared with the traditional batch process, such as machining, stamping, forging, precision casting and powder metallurgy.

Its advantage is mainly manifested in the density of the part, the tensile strength of the parts, surface finish of parts, small parts of, thin wall parts ability, part complexity, part design tolerance, parts in batch production ability, adapt to the range of material, availability etc. aspect, has the advantages of higher.



Manufacturing process of Apple watch adapter components

A new metal injection molding process for the production of the apple watch adapter will be a glass or sapphire embedded in the metal frame to form an integrated component. There are a number of methods that can be applied to the manufacturing process, in order to realize the integrated molding of the glass frame system components, and to ensure that the component tolerance is small enough and the system structure is stable.

The tolerance of the components made out of this will be very small. The edges of the glass can be cut or loaded into the channel to enhance the connection strength. Its finished product is one of the integrated display panel.

Analysis of powder metallurgy technology and its application

The application of powder metallurgy technology in ancient times, the first method of making iron is essentially used in powder metallurgy. And the development of modern powder metallurgy technology, there are three important signs:

1, to overcome the difficulties produced in the process of refractory metal casting, in 1923 powdermetallurgy cemented carbide was hailed as a revolution in machining.

2, thirty years, the successful preparation of porous oil bearing; and then the development of powder metallurgy iron based machinery parts, and give full play to the advantages of powder metallurgy less cutting and cutting.

3, in the 1940s, metal ceramic, dispersion strengthened materials such as, from the late 1960s to early 1970s, high-speed steel powder, Powder Superalloy have appeared, and the powder metallurgy forging and hot pressing technology gradually large-scale manufacturing parts with complicated shape and high strength.

Advantages of powder metallurgy technology

1, the vast majority of refractory metals and compounds, pseudo alloys, porous materials can only be manufactured by powder metallurgy method.

2, due to the powder metallurgical method can be pressed into the final size of the compact, and do not need or need little subsequent mechanical processing, it can greatly save metal, reduce the cost of products.

3, due to the technology of powdermetallurgy in the production process of the material does not melt materials, not mixed with impurities caused by crucible and deoxidizing agent and sintering general in vacuum and in a reducing atmosphere, not afraid of oxidation nor to any material pollution.

4, powder metallurgy method can guarantee the accuracy and uniformity of the composition ratio of the material.

5, powder metallurgy is suitable for the production of the same shape and the number of products, especially gear and other high processing costs of products, powder metallurgy process can greatly reduce production costs.

Can ABS for metal injection molding?

Do you know how to make Apple watch adapter?. It  is  made by metal injection molding process. Metal injection molding can OEM custom stamping part.

Then can it make ABS products like plastic injection molding?

The answer is No…

Though both are injection process, but materials are completely different. Now let’s see the material characters for ABS.

ABS material with good comprehensive performance, namely the high impact toughness and good mechanical properties. Excellent heat resistance, oil resistance and chemical stability, stable dimension, easy to machining, surface can also be electroplated and coated. Widely be used in car decoration and home appliance products

Strong moisture absorption, less than 0.3% moisture content, to dry before injection molding, 70 ~ 80 ℃ drying temperature for 2 ~ 4 h

ABS cannot stay too long in plastic injection machine, easy to aging and decomposition (decomposition temperature is about 250 ℃),the general temperature is 180 ~ 230 ℃.When mixed with recycled materials, should pay attention to control the proportion,  generally not more than 20%

Can PP be for Metal Injection Molding?

Do you know how to make Apple watch adapter?. It  is  made by metal injection molding process. Metal injection molding can OEM custom stamping part.

Then can it make ABS products like plastic injection molding?

The answer is No…

Though both are injection process, but materials are completely different. Now let’s see the material characters for ABS.

ABS material with good comprehensive performance, namely the high impact toughness and good mechanical properties. Excellent heat resistance, oil resistance and chemical stability, stable dimension, easy to machining, surface can also be electroplated and coated. Widely be used in car decoration and home appliance products

Strong moisture absorption, less than 0.3% moisture content, to dry before injection molding, 70 ~ 80 ℃ drying temperature for 2 ~ 4 h

ABS cannot stay too long in plastic injection machine, easy to aging and decomposition (decomposition temperature is about 250 ℃),the general temperature is 180 ~ 230 ℃.When mixed with recycled materials, should pay attention to control the proportion,  generally not more than 20%

What needs to use the powder metallurgy process?

At present, China's household electrical appliances has entered a stage of stable development, household appliances and materials quality is becoming increasingly important, especially widely used in household appliances, powder metallurgy process is particularly remarkable. Because some household appliances materials and parts can only be by the powder metallurgy method to manufacture, such as compressor refrigerator, washing machines, electric fans and other porous self-lubricating bearings;

some household appliances materials and parts with powder metallurgy method to produce better quality and lower prices, such as home air conditioner row fan and vacuum cleaners in the complex shape of the gear and the magnet etc.. In addition, powder metallurgy has important significance in maintaining the ecological environment, protecting the environment, saving energy and so on.

The application status of household appliances in powder metallurgy materials: according to the data, Taiwan powder metallurgy parts market distribution is as follows: car parts accounted for 19%, electric tools, accounted for 23%, household appliances account for 27%, mechanical parts accounted for l8%, sewing machine parts accounted for 13%. Obviously, the powder metallurgy materials used in home appliances have already possessed a large proportion, if combined with the domestic power tools and office machinery, its ratio is more considerable.

Powder metallurgy stainless steel structureparts have been widely used in home appliances. Such as 304L stainless steel powder metallurgy materials making parts for automatic dishwashers and washing machines, with 316L powder metallurgy materials making refrigerator ice maker launched disk, with 410L powder metallurgy material production limit switches and clutch etc.. Household dishwasher, clothes dryer, washing machines, sewing machines, vacuum cleaners, refrigerators, food mixer, gramophone, phonograph records, tape recorder, electric fans and other is also widely used in powder metallurgy copper based alloy.

ZCMIM see the future development trend of powder injection molding industry

ZCMIM was founded in 2007, now has 8 years of powder injection molding industry experience. Company has become one of the largest, most experienced metal powder metallurgical enterprises, supply 1500 a variety of metal powder products, plant area covers an area of 8000 square, its products are widely applied in many areas, including powder metallurgy parts, industrial metal parts, MIM parts, smart wearable metal accessories, apple adapter, stainless steel pinion, mobile phone metal parts supply and so on.

At present, China's powder metallurgy parts and bearing the total output value of more than 5 billion 500 million yuan, accounting for a smaller proportion of the global market, the development of space is also relatively broad. Through the continuous introduction of foreign advanced technology and independent innovation combination, powder metallurgy industry and technology of China are showing a rapid development momentum, industry one of the fastest growing parts of China general machinery industry, every year, the powder metallurgy industry, the output value of with high speed increasing.

With the rapid development of automobile industry, machinery manufacturing, metal industry, aerospace, instrumentation, hardware tools, construction machinery, electronic appliances and high-tech industries such as, for the powder metallurgy industry brought rare development opportunity and huge market space. In addition, the powder metallurgy industry has been included in the priority development and encourage foreign investment projects, the development prospects are broad.

Powder metallurgy forming

Powder metallurgy forming the main materials used, mainly in the form of 316L stainless steel, 316W, 304, and 17-4PH; iron-based powder; to complete the blank shape by injection molding plastic injection; injection embryo thing to note mold temperature, pressure, glue injection in different degree; deformation, material shortage, watermark; adverse phenomenon, resulting in different density, will directly affect the product's structure size and so on.

How did the apple watch adapter make it?

How did the apple watch adapter be made? mim watch adapter, for body parts and plastic parts, and then through the assembled; main component is by powder injection molding, debinding, sintering, to complete the main manufacturing, by surface treatment made of sand / polishing, electroplating to increase beautiful appearance effect;

Cutting tools should be cut from what angle?

Work part of the tool is to produce and processing chip part comprises a blade, the chip - breaking structure broken or furled, chip or channel capacity storage chip space, cutting fluid and structural elements. Some tool work is part of the cutting part, such as turning tool, cutter, boring and milling; some tool part contains the cutting portion and a part of the calibration, such as drill, reamer, reamer, inner surface broach and taps. The function of the cutting part is to cut the chip with the cutting edge, and the function of the calibration part is to repair the cutting surface and guide the cutting tool.

The working part of the cutting tool has three kinds of structure, the integral type, the welding type and the mechanical clamping type. The overall structure is on the knife body make cutting edge; welded structure is the blade brazed to a steel knife body; a mechanical clamp solid structure and two, a is the blade holder is fixed on the cutter body, another is the brazing of the cutter head is clamped on the cutter body. Hard alloy tools are generally made of welded structure or mechanical clamping structure; ceramic cutting tools are used in mechanical clamping structure.

In the choice of tool angle, need to consider the influence of various factors, such as the workpiece material, cutting tool material, processing properties (rough, finishing), etc., must be based on the specific circumstances of a reasonable choice.

Usually tool angle, refers to the manufacturing and measuring annotation angle in practical work, due to changes in the installation position of the tool and cutting movement direction, angle of practical work and annotation angle different, but differs very school manufacturing tool materials must have high temperature hardness and wear resistance, the necessary bending strength, impact toughness and chemical inertness, good manufacturability (cutting, forging and heat treatment, etc.) and not easy to deform.

ZCMIM company organization Huizhou 2 days of self driving tour

Recently everyone busy tired, hard to find time to take a break, there is a chance to breathe, the company decided to organize the organization boss travel once, on Friday afternoon together on their own departure to Huizhou ten mile Silver Beach.

Our first stop is the villa residential district, Friday afternoon 5 points nearly to the other side of the, but hurried so coincidentally, rain, had to buy good food, barbecue and cooking, ready to cook for yourself, busy the delight. Tidy up 10 points after dinner, playing cards, wash wash, watching TV watching TV, suddenly feel our family is very warm side!

The next day morning has been in the rain, but there have been some small partners t go out to see the sea, after lunch it didn't rain a lot. We'll start to Xunliao Bay fishing, scavenging for fish is looking for a place to make fish soup for dinner, after dinner to return to live in the place, freedom of movement.

On the third day after breakfast went to the seaside to swim, Xiaobian to ending their breakfast, 10:30 started to drift Nanshan, arrived to eat 12 o'clock already, eat first, 13 30 look Nanshan drifting who drove over to pull us to the destination, began to get off the boat to play.

To afternoon 4 points for each of the back drive. All the crew members ZCMIM company play this to is quite satisfactory, the annual ZCMIM are will be held once or twice, travel, play activities, although the MIM industry in China still do not know, in a foreign country but to use this process very much, so ZCMIM small partner every day is very busy to release your pressure. The company's treatment as well as for employees to take into account the benefits is very let us recognize that all employees of ZCMIM will work together to create a better life in the future!

Structure of Metal Injection Molding Injection Machine

The structure for injection machine in metal injection molding process is constituted by 5 parts, they are:

1.        Injection Components

2.        Clamping Unit

3.        Hydraulic System

4.        Electrical Apparatus Control System

5.        Peripheral System

Injection Components

Injection components including: plasticizing unit (screw, screw head, non-return ring, thrust collar, mixing  rings, cylinder, nozzle), injection port, injection oil cylinder, folding driving device (oil motor, reducer, etc.), injection portl cylinder, etc

Clamping Unit
Clamping unit parts  include:  clamping device, mould adjustment system, ejection device

Hydraulic System
Hydraulic system components are: hydraulic pump, motor, valve, Accumulator, hydraulic oil cooler, filter, pipeline, hydraulic accessories

Electrical Apparatus Control System
Components are: process control system, temperature control system, pump motor control system, safety device, fault monitoring, alarm system, operation and display device

Peripheral System
The peripheral system is:  feeding system, drying system, manipulator, crushing machine, hot runner temperature controller for mould

Injection Molding Process for Apple watch adapter

So many people know that apple watch adapters are made by metal injection molding process. And it is quite easy to search metal injection molding process in internet. Or you can check in this website: www.zcmim.com.

 But  how many do you know about plastic injection molding process? Do you think those two process have something in common? Yes, their injection machine is almost same but process is different greatly.

The process of injection molding contains the following four processes:

1.Plasticizing Process
Plasticizing process refers to heating, transporting, compacting, cutting, mixing, homogenizing plastic material in the cylinder

2. Mold Filling

Under the thrust  from oil cylinder, pushing solution from nozzle , to mold cavity through mould runner and sprue.

3. Pressure Maintaining &Feeding Process

Continue to fill vacant due to shrinkage of volume

4.Cooling and Sizing Process

Freezing the sprue after pressure maintaining &feeding process. Products form after a time of cooling

5.Pick-up Process

Acquired a good rigidity and intensity after a time of cooling, eject  products from ejector rod

Comparison between MIM technology and precision manufacturing and traditional machining

MIM process and the traditional powder metallurgy method is used in the die casting process of aluminum and zinc alloys, such as low melting point, liquid flow of good material. The product of this process is limited by material, its strength, wear resistance and corrosion resistance are all limited. MIM process can be processed raw materials more.

Precision casting process, although in in recent years the product precision and complexity are improved, but still less than dewaxing process and MIM process, powder forging is an important development, has been applied to the connecting rod mass production. But in general, the forging heat treatment in engineering cost and die life is still a problem, yet to be further solved.

Traditional machining method, recently by automation and enhance the processing capacity, have great progress in the effect and precision, but the basic procedure still do not take off a production step by step (lathe, planer, milling, grinding, drilling, polishing and so on) to complete the shape of the parts.

Machining method is much better than other processing methods, but because of the low efficiency of the material, and its shape is limited by equipment and tools, some parts can not be completed with mechanical processing. On the contrary, MIM can effectively make use of the material, without restriction, for the shape of small, high difficulty of precision parts manufacturing, MIM process is the mechanical processing, the cost is low and the efficiency is high, with a strong competitive edge.

Application of cemented carbide tools

Hard alloys can be used in the chemical vapor deposition method has been coated with titanium carbide, titanium nitride, aluminum oxide hard or composite layer. Is the development of physical vapor deposition method can be not only used for hard alloy tool, can also be for high-speed steel cutting tools, such as drill hob, taps and milling. Hard coating as hinder chemical diffusion and heat conduction of the barrier, the cutting tool in the cutting wear slower. The life of blade coating and coating compared to increase about 1 ~ 3 times

Because in high temperature, high pressure, high speed, and in corrosion of fluid medium, the parts, the application of difficult to machining materials more and more, the level of automation of machining and on machining accuracy requirements become more higher.

In order to adapt to the situation and direction of development of the tool will be the development and application of new cutting tool materials; further development tool of gas phase deposition coating technology, with high strength and high toughness matrix deposition higher hardness of the coating, the better to solve tool material hardness and strength of the spear shield; in the further development of the structure of indexable tool; improve the manufacturing precision of the cutting tool, reduce the difference between the quality of the products and make the tool used to achieve optimization.

Comparison between MIM technology and precision manufacturing and traditional machining

MIM process and the traditional powder metallurgy method is used in the die casting process of aluminum and zinc alloys, such as low melting point, liquid flow of good material. The product of this process is limited by material, its strength, wear resistance and corrosion resistance are all limited. MIM process can be processed raw materials more.

Precision casting process, although in in recent years the product precision and complexity are improved, but still less than dewaxing process and MIM process, powder forging is an important development, has been applied to the connecting rod mass production. But in general, the forging heat treatment in engineering cost and die life is still a problem, yet to be further solved.

Traditional machining method, recently by automation and enhance the processing capacity, have great progress in the effect and precision, but the basic procedure still do not take off a production step by step (lathe, planer, milling, grinding, drilling, polishing and so on) to complete the shape of the parts.

Machining method is much better than other processing methods, but because of the low efficiency of the material, and its shape is limited by equipment and tools, some parts can not be completed with mechanical processing. On the contrary, MIM can effectively make use of the material, without restriction, for the shape of small, high difficulty of precision parts manufacturing, MIM process is the mechanical processing, the cost is low and the efficiency is high, with a strong competitive edge.

Development of powder metallurgy industry

Powder metallurgy technology in China is in the seventies and eighties of the last century developed, not too late to start, but the development is not fast enough, not only in the number needs to be improved, in the variety and quality also needs to improve, such as powder performance needs to be improved, compressibility, chemical composition needs to be improved, variety, specifications and grades to further enrich and consistency in the quality of relatively poor problem to be resolved as soon as possible, especially to improve production efficiency, reduce the manufacturing cost, in order to adapt to the increasingly fierce international and domestic two market competition.

The first problem to be solved in the development of powder metallurgy is education. It is understood that at present, only the national Central South University, Northeastern University, University of Science and Technology Beijing and HeFei University of Technology, and several other institutions with a powder metallurgy. The second is to go out, the introduction of. In order to promote the development of powder metallurgy industry in China, the powder metallurgy industry in China should strengthen the communication with the international industry.

Third is to formulate the corresponding policies to support the development of new industries as a powder metallurgy technology. Like, over the years China has been from abroad to import large quantities of containing MNS prealloyed easy cutting steel powder and low alloy steel powder, water atomized iron powder production enterprises to promote the development and application of, the pre alloyed steel powder is duty bound, but the government should have the related policy support

Method for producing iron powder

China's manufacturing industry must change the mode of growth, green manufacturing will become the direction of sustainable development of China's manufacturing industry. By the change of the growth mode of the manufacturing industry, to further promote the development of China's powder metallurgy industry, commonly known as iron powder, its accurate name should be iron and steel powder.

Powder metallurgy material is closely related to our life, not only in the automotive, aerospace, military and other industries is an essential material, but also in the refrigerator, washing machine, air conditioning and other household products are also a large number of applications. China is now the production of iron and steel powder mainly has four kinds of methods: atomization, reduction, electrolysis and carbonyl. Carbonyl method can obtain nanometer powder, purity is high, the cost is very high, mainly for the military field; electrolytic method almost can produce all metal powder, fewer impurities, high purity, used for chemical industry; reduction method and spray method is the more economic and yield large iron and steel powder preparation method that is widely used in mechanical manufacturing industry, large quantities of parts and components production.

The formation process of British metal watchband

Watch adapter; strap, the powder injection molding process, the mold development, injection molding, sintering, to meet the requirements of the technology of the production of products, the main material for 316L stainless steel, and 17-4PH, raw powder; surface finish, causing uniform density; on the surface of the product, and sandblasting, polishing to complete; increase the appearance effect; need for plating surface treatment can better anti sweat, rust, and to higher surface effect;

Mobile phone vendors are mainly targeted at those areas?

The application of electronic mobile phone industry and 3C products, mobile phone Cato, switch to health and health volume, headphone connector, and camera decoration parts, is widely used in mobile phones and electronic products; main material is 316L, has good appearance, 90% can one-time molding of requirements, through the plastic part, or part of the process can meet the technical requirements, MIM industry production and processing to achieve a more places.

Strict requirements for selection of binder in metal injection molding

In the MIM metal injection molding, the binder plays an integral role, so what is the strict requirements for the selection of binder?

1 defect control, including the elimination of weld marks, cracks and voids

2 improve process yield, low degree of deformation

3 size control, good binder can maximize the size of the same size and shape of the product

4 carbon control, bonding agent is very easy to pollution products

Through the above, do you have a metal injection molding process of the binder to learn more about it?

ZCMIM for you to simply introduce the classification tool

The tool can be divided into five types according to the surface of the workpiece. Processing a variety of outer surface of cutting tool, which comprises a lathe, planer, milling cutter, the outer surface of the broach and file and so on; hole processing tools, including bit, reaming drill, cutter, reamer and the inner surface broaches; thread cutting tools, including tap, die, the automatic opening and closing thread cutting head, thread turning tool and thread milling cutters; gear cutting tools, including hob, pinion cutter, shaving cutter, bevel gear processing tool, cutting tool, including inserted tooth saw blade, band saw, hacksaw, cutting tool and the saw blade milling cutter and so on. In addition, there is a combination of cutting tools.

According to the cutting motion mode and the corresponding cutting edge shape, the cutter can be divided into three types. Universal cutter, such as lathe, planer, milling cutter (not including the forming tool and forming tool and forming milling cutter), boring cutter, drill, reamer, reamer and saw; forming cutter, this type of tool blade with be workpiece processing section of the same or nearly the same shape, such as the forming tool, planer tool forming, forming milling cutter, broach, taper reamers and various thread processing tool; generating tool is generating method for machining of gear tooth surface or similar workpieces, such as hob, pinion cutter, shaving cutter, bevel gear planer and bevel gear milling cutter and other.

The structure of each cutter is composed of a clamping part and a working part. The clamping part and the working part of the whole structure tool are made on the cutter body; the working part of the inserted tooth structure cutter is inserted on the cutter body.

The clamping part of the cutting tool has two kinds, which are with hole and handle. With hole cutter rely on inner hole is sheathed on the machine tool spindle or the spindle, with axial or end keys to transfer torque, such as cylindrical milling cutter, a set of type face milling cutter and so on.

The handle of the tool is usually rectangular, cylindrical and taper shank three. Lathe, planer tool, etc. generally rectangular handle; taper shank by taper bearing axial thrust, and with the help of the friction torque; cylindrical shank generally applicable to smaller twist drill, a vertical milling cutter, cutting by means of clamping frictional force transfer torque. A lot of tool with handle handle made of low-alloy steel, and part of the two parts with high speed steel butt

Looking for a good way to overseas customers

Want to look for overseas customers, the development of the international market, the first must be in the country to form a competitive product. Second is the talent. Third is the technology. ZCMIM started by the cell phone part supplier, the production of products including the metal watch straps uk，metal injection molding nozzle, etc..

Seek customer channels there are many, from the original participate in overseas exhibitions, contact foreign trade promotion company, development to today's e-commerce and direct web search, and variety of shapes and sizes of foreign buyers purchasing pairing until the search market.

Powder metallurgy gear and reduction gear box is how to work it?

Powder metallurgy can make the gear carrier, the gear, including gear body, in gear inside the body of the week is provided with a gear and full of inner circumference of the gear body and the gear on the outside of the set has at least six positioning block; and speed reduction gear box gear provided by the utility model can and other supporting components fast and convenient for fixing, clamping, so as to improve the stability of the gear mechanism, and because of the gear is through the metal powder pressed into a shape, to avoid the trouble artificial or stamping forging process, and more suitable for mass production and high efficiency.

Copper base powder metallurgy thrust ring and preparation method thereof

Copper base powder metallurgy thrust ring and preparation method thereof, in particular to the powder metallurgy thrust ring, thrust bearing and other parts of the copper, tin, lead and graphite mixed components used in the marine gear box, and the preparation method thereof. The copper core plate is coated with tin bronze powder as an adhesive layer, and the composite copper base powder metallurgy friction reducing layer on the adhesive layer is used;

Copper based powder metallurgy friction reducing layer consists of tin powder 8 ~ 10%, lead powder 4% to 2, graphite powder 1% and the rest for copper powder. The formula is applied to the following steps: copper plating layer, coating adhesive layer and composite copper base powder metallurgy friction reducing layer, pre sintering, pressing oil groove, re firing, and sintering. A copper based powder metallurgy thrust ring and a preparation method thereof are of low pressure, high strength, low manufacturing cost and high finished product rate.

Special lubricant for powder metallurgy gear

With the development of industrial automation, the powder metallurgy products industry developed rapidly, and the application field is no longer confined to the mechanical equipment industry. Today, Chaodeng in place, also often see powder metallurgy products, technology products, such as ceramic production. Powder metallurgy products have been widely used in all walks of life.

Prospects for the development of powder metallurgy industry in recent years, through the continuous introduction of foreign advanced technology and independent innovation combined, powder metallurgy industry and technology of China presents the rapid development trend, industry one of the fastest growing parts of China general machinery industry, every year, the powder metallurgy industry output value to 35% speed increase.

The global manufacturing industry is accelerating the transfer to China, the rapid development of automobile industry, machinery manufacturing, metal industry, aerospace, instrumentation, hardware tools, construction machinery, electronic appliances and high-tech industries such as, for the powder metallurgy industry brought rare development opportunity and huge market space. In addition, the powder metallurgy industry has been included in the priority development and encourage foreign investment projects, the development prospects are broad.

Powder metallurgy hydraulic press is designed for foundry and scrap metal processing. This machine is suitable for powder and granular cast iron, copper scrap, steel scrap and other scrap metal cold pressed cake into a cylindrical furnace using direct investment. The machine has a high degree of automation, which can reduce the waste of materials and improve the productivity of the users.

This machine adopts the advanced machine, electricity, liquid, gas integration control, with automatic feed feeding device, floating pressing, effectively control the density of molding, demoulding and general release protection etc. to choose from, the hydraulic system using advanced combination of valve block, ensure liquid continuous press, frequent stable work; three filling, shaping, demoulding position mechanical gear positioning block and stepless adjusting mechanism to determine the geometric dimension of the product is stable and adjustable. Oil cooling device. The use of PLC and man-machine interface centralized control, and equipped with mechanical limit device, so as to ensure the consistency of products.

With the development of the market, the factory must rely on advanced technology and good management to win the competition in the market. We will with our strong technical strength, keep the spirit of innovation, excellent product quality, perfect after-sales service to our customers and friends to provide high quality and low price of high-tech products, for the factory to win a broad market space for survival.

Application and design of powder metallurgy iron base structure parts

20th century 30 years of powder metallurgy iron-based structure parts first in the automobile industry has been some applications, until now, in North American production of powder metallurgy structural parts of 70% above is still used in the automobile industry, in Japan even higher to reach the 90%. Their applications have been rapidly expanded to the agricultural machinery and gardening equipment, household appliances, power tools, office equipment and other uses. Powder metallurgy structural parts have been replaced in cast iron, forged steel primary or bar machining and sheet metal stamping job.

The main advantages of the powder metallurgy parts are that, under the conditions of higher productivity and lower labor cost, the parts with more dimensional tolerances can be produced. Usually, and rival of the metal forming process is compared, the cutting amount is small or no need of cutting processing, do not need to cutting expensive metal cutting machine tool, cutting tool, equipment account for the venue and technical workers.

Powder metallurgy structural parts in the early stages are used to replace parts produced by other methods. Even today, for many applications, it is still the case. However, in order to make full use of the advantages of powder metallurgy process, such as energy saving, material saving, and now more and more parts from the beginning of the design is the use of powder metallurgy process. This technological progress, and product designers and parts manufacturers of the mutual exchange, coordination and cooperation is increasingly related to.

Products not only to the use of conditions, performance requirements to design, but also to take into account the advantages and disadvantages of the expected manufacturing process. In the early stage of product design, the powder metallurgy process should be considered as a possible production process. When considering the design of powder metallurgy structural parts, it is necessary to consider how to press forming. This involves the use of a single axial rigid mold to suppress the principle of metal powder.

PM China 2016 Shanghai Powder Metallurgy Exhibition Experience

"From metal powder, injection maching, MIM furnace, inspection machine to post process and high-precision metal products and other medical device parts which made by metal injection molding process, there was plenty to be discovered on the exhibition floor of 2016 International Powder Metallurgy Exhibition, held at Shanghai Everbright Convention & Exhibition Center  on April 27-29 2016."

"ZCMIM has been regularly participating in the exhibition and this year the response was phenomenal. With a magnificent stall set up at the venue, ZCMIM with its innovative step in the manufacturing industry could easily pull in lot of interested visitors. Lot of curious visitors were impressed by the displayed MIM parts and enquired for details."

The event was organized by PM CHINA & IACE & Cemented Carbides Expo Organizing committee,Ever since the first successful show in 2008, PM CHINA has run well  for eight years and has received strong support and participation from industry associations at home and abroad.The exhibition keeps expanding every year and number of exhibitors and visitors hits records high in 2015. Global famous professional magazine--PM Review and Germany Ceramics Forum International & Ceramics Application cooperate to report the event continuously.PM China has become one of the most important information collection and exchange centers for PM industry.

"The exhibition has definitely gathered some good interest & initial enquiries, which can result to long term production programs and open new market for ZCMIM. ZCMIM is definitely looking forward to participate for the upcoming year as well to herald unique upcoming technology to reach large medical customer base

PM China 2016 International Powder Metallurgy Exhibition

Exhibitor: ZCMIM Technology Ltd

Date : Apr 27th to 29th 2016

Exhibition Address : Shanghai Everbright Convention & Exhibition Center
